The airPoint™ Nexus is a LongRange™ multi-band access point used in Near-Line-Of-Sight deployments for high performance last mile wireless infrastructure.

Built on the award winning Nexus platform, the airPoint™ Nexus (sB3210) can deliver 15Mbps throughput for 3 - 5 mile (6 - 8 Km) links. The airPoint Nexus is a value-creating access point that is intelligent, carrier class, easy to deploy and easy to maintain.

Value-Creating License free broadband

Why pay for expensive licensed bands when you experience RF congestion? The airPoint Nexus utilizes the license free ISM (and UNII) bands in 2.4Ghz and 5.2 -5.8 Ghz frequency and supports IEEE 802.11b, 802.11g and 802.11a standards.

In the event of RF congestion, the Nexus’ software tunable radios give Wireless ISPs the freedom to change frequency bands and standards, thus providing high availability to clients. WISPs can choose via software between:

• · 14 Channels in the 2.4 Ghz ISM Band,
• · 4 Channels in the 5.25 to 5.35 Ghz UNII Band,
• · 11 Channels in the 5.50 to 5.70 Ghz UNII Band or
• · 4 Channels in the 5.725 to 5.850 Ghz ISM Band.

Carrier Class Robustness

Having difficulty with wireless deployments in extreme operating environments? The airPoint Nexus is designed for carrier class reliability in operating environments ranging from -45º C and +60º C (-50º F to 140º F) at 5% to 95% non-condensing humidity. Maintaining the signature smartBridges reliability under extreme conditions, the airPoint Nexus is ideal for very hot or cold climates and/or very humid or dry conditions.

airPoint Nexus (sB3210)
Specification Overview

· Operating Mode –Access Point, Wireless Distribution System (WDS)

• · MAC based bandwidth control
• · High Transmit Power and receive sensitivity
• · Layer 3 Routing – RIP v2
• · DHCP server and Relay
• · Web and SNMP based Management
• · Built-in MAC Authentication table and external RADIUS servers (multiple servers for redundancy).
• · Block client to client communication for ensuring privacy.

The weather and rust roof plenum rated casing with protected stainless steel N-connectors give added protection from the environmental conditions.

Quick and Easy Deployment

Deployment has never been easier. With our easy to use access points, simple to use software and our audio tone antenna alignment aid, the network can be setup in less than one day.

Dual Ethernet Ports allows for Back to Back connectivity (or daisy chaining) with other Ethernet enabled devices (like IP Camera's or VoIP phones) for added convenience.

Daisy chaining of access points can also be used for redundancy or repeater mode of operation.

Ease of Maintenance

Maintenance is convenient with the airPoint Nexus, with continuous automatic client link monitoring and optimization, the network monitors itself leaving you to concentrate on your core work. In addition, remote management over a web user interface means that you can manage the network without leaving your office.
